Jet Press 1160CFG

Next generation inkjet press for commercial web applications

Jet Press – setting new standards

Groundbreaking digital inkjet web press

The Jet Press 1160CFG features a unique paper stabiliser unit to ensure high coverage print is delivered with consistent 1200 dpi quality at up to 160 metres per minute

Tot wel

160 metre

per minute

4 colour

CMYK

printing

High coverage

1200 x 1200 dpi

quality

Wide

64 to 250 g

paper weights

Why Jet Press 1160CFG?

Achieve 1200dpi quality at print speeds up to 160 m/min

Unique paper stabiliser unit optimises quality and speed

1200 x 1200 dpi quality at 80 m/min even on 250g coated stock

1. Unwinder

2. Tension controller

3. Edge guide

4. Paper Stabiliser Unit

5. Printhead unit

6. Dryer

7. Sub-Drying Unit

9. Rewinder (Optional)

8. Control panel

10. Ink Pack Cart

Slack Web Unit (Optional)

Fujifilm has applied its market-leading technologies in the Asia Pacific region to introduce the Jet Press 1160CFG – a groundbreaking inkjet press setting new standards for commercial web applications.

Groundbreaking new digital inkjet press for commercial web applications

The Jet Press 1160CFG features a unique paper stabiliser unit that maximises print quality at high speeds, expands the range of printable applications, and minimises wavy sheets, particularly prevelant with the printing of books on coated stocks with high ink coverage.

A new standard in digital print quality

The key to the Jet Press 1160CFG’s advanced capability is a unique Paper Stabiliser Unit that ensures high coverage, 1200dpi quality print is delivered with consistent high quality and reliability.

This unique technology eliminates the two major challenges associated with water-based inkjet technologies used in high speed presses:
• Controlling the behaviour of a range of paper types
• Effective drying of inkjet printed paper

Advanced Paper Stabiliser Unit

Paper is often the most difficult variable in the printing process to control. It can react differently depending on the local humidity, temperature and other outside factors.

The Paper Stabiliser Unit is not a pre-coat or priming station. There are no consumables to apply, replenish or pay for. The paper stabiliser does exactly that, eliminating the stress and shocks that paper normally experiences in other inkjet presses.

Precisely controlled heating and cooling of the paper before printing conditions the paper for a smooth, stress-free progression through the press, to give the best possible printed result.

Before entering the imaging section, the paper goes through a pre-drying process which minimises rapid paper expansion and contraction within the press. The paper stabiliser helps to reduce paper curling and misalignment, ensuring a smooth and stable paper feed, thereby increasing registration accuracy, improving print quality and reducing waste.

The benefits of paper stabilisation:

Multiple benefits of paper stabilisation

The Jet Press 1160CFG won’t shrink away from a challenge

The paper stabiliser reduces the cycle of paper shrinking and swelling with each round of printing and drying. Dimensional stability is dramatically improved leading to accurate and reliable front to back registration.

Early intervention from the paper stabiliser reduces the stresses and strains on the paper as it is printed. Swelling and shrinking is eliminated improving the condition of the paper throughout the print process.

Minimise wavy sheets and books

The chance of producing wavy books is reduced too. This is essential for high quality print on coated stocks with higher ink coverage, which are the most susceptible to waviness. The phenomenon of swelling and shrinking is even more pronounced between areas of heavy ink coverage and non-image areas. The stresses of heating and cooling, wet and dry, are significantly reduced with the Jet Press 1160CFG, leading to flatter sheets and books. Less stress means flatter books.

Stabilised paper, represented by the green line, swells and shrinks less as it carries less moisture overall from the start of printing the first side, to the end of drying the back side.

Mediaflexibiliteit

The Jet Press 1160CFG paper stabiliser helps expand media compatibility including common offset stocks. You can also print on both thinner and thicker stocks, meaning you can take advantage of current paper stocks, simplifying inventory and reducing costs.

Prints beautifully on offset coated paper

The newly developed aqueous pigment ink prints beautifully on both coated and uncoated paper without a primer. By reducing moisture levels before printing, the Jet Press creates a less volatile environment for the paper with

lower changes in temperature and moisture content. Paper stabilisation reduces issues at the time of printing and down the line during post processing and finishing.

Avoid dirty guide rollers and print white spots

Without the paper stabiliser, ink can attack the paper coating by penetrating deep into the paper base. This leads to a weak surface that can be picked off the sheet making guide rollers dirty and leaving white spots in the print.

Stabilised paper has a more robust surface, avoiding white spots and providing better rub resistance of the finished print.

Key scenarios where the Jet Press 1160CFG may fit in your business

You need to produce short to medium run, high quality colour books, journals, brochures and catalogues

The Jet Press 1160CFG has the quality and speed to produce high quality publications on light to heavyweight stocks. Its unique features overcome the common challenges facing other, less capable high speed inkjet presses.

You need to fulfil direct mail campaigns in medium to high volumes on quality stocks

Direct mail is changing to compete in an ever-more challenging communications environment. As campaigns become more creative and targeted, the Jet Press 1160CFG has the capability to run higher quality mail pieces at higher speed with greater consistency.

You need to move jobs away from analogue processes that are less capable and efficient

Offset printing presses are ideally suited to long run, static jobs but are increasingly being used for short to medium run work. Presses become stacked with inefficient work leaving little time for the jobs that pay. Jobs moved to the Jet Press 1160CFG can be produced on the same paper stocks at comparable quality using technologies exclusive to Fujifilm.

Fujifilm is ideally placed to maximise the benefits of this exclusive system with:
• A heritage in inkjet printing over the last 25 years.
• A long history of continuous inkjet printing, with the highest market share for the supply and service of these presses in the Asia Pacific region.
• A deep understanding of the print industry with over 90 years experience – from the supply of offset plates and film to the latest digital technologies.

Control colour with cloud-based colour management

Deliver high quality, consistent and accurate colour output while optimising workflow efficiency and productivity.

XMF ColorPath, Fujifilm’s cloud-based colour management system, allows printers to create optimised colour profiles and calibrations to print to various standards, and provides tools to ensure that over time the standards are continually adhered to, all while achieving superior print results and meeting the demanding requirements of today’s print market.

Manage and monitor colour performance

The key to good colour management is the creation of accurate device link colour profiles, the ability to easily print to ISO standards, and above all to have a system that makes it easy to check and verify that standards are continuously being met. All of this and more is achieved with XMF ColorPath, Fujifilm’s cloud-based colour management solution. Optimised curve data and ICC profiles can be quickly and easily created in the cloud and deployed for everyday production within XMF Workflow.

Belangrijkste kenmerken
• Cloud-based colour management
• Align offset and digital presses to ISO or G7 standards
• Optimise ink usage while maintaining conformance to ISO and G7 standards
• Create optimised colour profiles to allow for GRACoL and FOGRA standard proofing
• Verify if digital proofs and prints are within the tolerance limits of industry standards
G7® and GRACoL® are trademarks of Idealliance Control your colour.

Working towards a more sustainable future

The Jet Press 1160CFG can replace traditional offset production for a variety of print jobs, therefore bringing the sustainability benefits of digital printing to a wider range of print production.

The many environmental benefits of digital print are well documented, including the elimination of make-ready waste between jobs, the removal of the plate production process, the requirement for fewer press chemicals, and smaller stock holdings due to the on-demand nature of digital print.

Folding carton packaging

A press that combines high quality and high speed

The Jet Press 1160CFG has two modes relating to speed and quality. A High Quality (HQ) mode running at a 1200 x 1200 dpi resolution and a High Performance (HP) mode with a print resolution of 1200×600 dpi.

Fujifilm hybrid ink technology, optimised for continuous feed printing

The Jet Press 1160CFG, combined with Fujifilm’s hybrid ink, can print in both quality modes without the need for a primer. The patented hybrid ink formulation controls ink penetration, surface tension and coagulation to print at high speed with rapid drying, resulting in sharper dots and reducing strike through.

High definition and even dot shape for a better print result

Reducing moisture content during paper stabilisation improves dot shape and reduces graininess. The end result is higher productivity and a winning combination of better quality print, at higher resolutions, and at faster speeds.

Lower show through, the difference is striking

Another benefit of lower moisture content in the paper is reduced strike through on thinner paper stock. With less moisture due to the paper stabiliser, the ink stays nearer to the surface of the paper. Less penetration of the ink into the coating and paper fibres means lower show through.

This principle of early paper stabilisation with the Jet Press 1160CFG is far more effective than heated air or rollers alone during later stages of the print process. The result is a combination of high quality print and high production speeds with a consistency and efficiency not seen before in this type of press.

Consistent print that lasts

Great print needs to stay great and creating robust, long-lasting images needs great science. The Jet Press 1160CFG combines Fujifilm’s renowned hybrid ink chemistry and the unique physics of the paper stabiliser to bring outstanding print durability to high-speed inkjet.

Many presses printing high resolution on coated stocks need to slow down to 50 metres per minute or less. When paper is stabilised on the Jet Press 1160CFG, lower moisture content means the paper surface can withstand more power and run at higher speeds.

Image quality can suffer when jetting onto paper that has not been stabilised and moisture content is high. If the surface tension in the ink is disturbed by microscopic moisture elements in the paper, uneven dot shapes will make images appear grainy and text will be poorly defined too.

Meer informatie…

Find more details and key specifications in the Jet Press 1160CFG product brochure, available for download now.

De brochure downloaden

Revoria Press EC2100

Nieuwste generatie 4- en 5-kleuren middenklasseprinters.

Nieuwste generatie printers

Het is tijd om uw printwerk naar een hoger plan te tillen

De Revoria EC2100S & EC2100S printers bevatten een reeks geavanceerde technologieën voor baanbrekende prestaties, kwaliteit en veelzijdigheid in toepassing. De Revoria EC2100S beschikt ook over een vijfde kleur waarmee u een breder kleurengamma en speciale effecten kunt printen om op te vallen in een steeds veeleisender markt.

Tot wel

100ppm

A4 CMYK

Tot wel

5 kleuren

52 tot 400 g

mediagewicht

Maximale mediaformaat

330 x 1300mm

mediaformaat

Waarom de Revoria Press EC2100 & EC2100S?

5-kleuren printwerk voor een breder kleurengamma en bijzondere effecten die opvallen

200 gepatenteerde nieuwe technologieën voor een toonaangevende veelzijdigheid in toepassingsmogelijkheden

Baanbrekende productiviteit, kwaliteit en prestaties voor een middenklasseprinter

Maak kennis met 5UPERKLEUR van Revoria. Twee nieuwe middenklasseprinters die een vijfde kleur samenbrengen met buitengewone prestaties om op te vallen in een steeds veeleisender markt.

Toonaangevende middenklasseprinters met geavanceerde kleurmogelijkheden en prestaties

De Revoria EC2100 & EC2100S leveren niet alleen betere prestaties, maar ook de voordelen van 5-kleurenprint, waarmee u uw bedrijf kunt onderscheiden.

Voortreffelijke benchmark printkwaliteit

Super EA-Eco-toner

Bij Super EA-Eco-toner is de grootte van de tonerdeeltjes teruggebracht tot een van de kleinste in de branche en is de vorm gestandaardiseerd voor scherpe weergave van gedetailleerde tekens en fijn lijnwerk.

Daarnaast worden verlopen, halftonen en middentonen gedetailleerder en puntvormen natuurgetrouwer gereproduceerd, wat een uitzonderlijk hoge printkwaliteit geeft.

LED-printkop

De Revoria Press EC2100 & EC2100S maken gebruik van een LED-printkop met hoge resolutie, waarmee ze printwerk van uitzonderlijk hoge definitie produceren:

2400 x 2400 dpi LED-printkop
Levert uitvoer in hoge resolutie voor scherpe lijnen en beelden, wat printen in hoge definitie mogelijk maakt.

Ruimtebesparend, energiebesparend
De grootte van de LED-printkop is teruggebracht tot 1/12 van die van de vorige generatie VCSEL-ROS die voorheen werd gebruikt. Omdat de printkop geen motor heeft, verbruikt hij weinig stroom, maakt hij geen geluid en is de beeldreproductie zeer stabiel.

Hoge beeldkwaliteit
Om de hoge beeldkwaliteit te bereiken die nodig is voor productieprinters, hebben we de ontwikkel- en transferunits en daaraan gekoppelde technologieën verbeterd en doorontwikkeld.

Realtime, intelligente printoptimalisatie

De Revoria Press EC2100 en EC2100S zijn voorzien van optionele slimme monitorfunctie D1 die de kleur en registernauwkeurigheid van de voor- en achterzijde van printopdrachten monitort tijdens het printen.

Maximale productiviteit en inzetbaarheid

Printen op topsnelheid van 100 ppm met alle papiergewichten

De Revoria Press EC2100 en EC2100S kunnen maximaal 100 ppm printen in A4-formaat met CMYK, en maximaal 55 ppm in A3-formaat met CMYK. Deze snelheid wordt bereikt voor alle

Nieuwe bias transferband

Het gebruik van een nieuw Bias Transfer Band-systeem (BTB) in plaats van de conventionele Bias Transfer Rol (BTR) maakt het papiertransport stabieler en dus betrouwbaarder, zodat u nog meer toepassingen kunt printen. Het nieuwe systeem past de nipdruk automatisch aan op basis van de dikte van het papier, wat de overdracht van de toner verbetert. Dit mechanisme is nieuw voor de Revoria EC2100 & EC2100S en produceert een superieure printkwaliteit, met name op reliëfpapier.

Transfermechanisme aan voorrand

Fujifilm heeft de EC2100 & EC2100S uitgerust met een vliegwiel dat de transferbandrol een traagheidskracht geeft voor een stabiele aandrijving. De rotatie van het vliegwiel en de traagheidskracht onderdrukken de trillingen van de transferband, waardoor een stabiele overdracht van media wordt verkregen, zelfs bij zwaar papier.

Nieuwe ontwikkeltechnologie

Verslechtering van de ontwikkelaar is een van de redenen waarom de printkwaliteit na een bepaalde periode onstabiel kan worden. Bij conventionele horizontale markeermodules kan een deel van het ontwikkelingsmateriaal dat is gebruikt opnieuw naar de ontwikkelrol gaan, wat de printkwaliteit nadelig kan beïnvloeden.

In het nieuwe verticale ontwikkelsysteem dat in de EC2100 & EC2100S wordt gebruikt, wordt het ontwikkelingsmateriaal vernieuwd voordat het wordt teruggevoerd naar de ontwikkelrol. Op deze manier is al het gebruikte ontwikkelingsmateriaal altijd ververst en in optimale conditie, waardoor de Revoria EC2100 & EC2100S ook na verloop van tijd mooi blijven printen, vooral op dik, ruw en reliëfpapier.

Toonaangevende mogelijkheden voor papierverwerking

De Revoria Press EC2100 en EC2100S hebben nu een reeks geavanceerde markeertechnologieën met verbeterde papierverwerkingsmogelijkheden, waardoor meer soorten toepassingen kunnen worden geprint en de inzetbaarheid van de machine toeneemt voor een breed scala aan

Reliëfpapier, ruw papier, dik papier
Het nieuw ontwikkelde Advanced Single Layer Belt (A-SLB), secundaire transferschakelmechanisme, in combinatie met de tonerconditiestabilisatie hebben de overdracht van toner op reliëfpapier en dik papier aanzienlijk verbeterd.

Gewoon papier, ruw papier
Door zowel de beeldvormings- als beeldtransfertechnologieën te verbeteren, hebben we de printkwaliteit verbeterd voor gewoon en ruw papier. Daarnaast hebben we voor elke papiersoort een optimale transfertechnologie ontwikkeld voor stabilisatie van de elektrische velden, waardoor met een meer uniforme dichtheid kan worden geprint.

Dik papier, enveloppen
Twee nieuwe technologieën voor papiertransfer leveren een toonaangevend papierverwerkingsvermogen voor dik papier en enveloppen:

• Nieuw secundair transfermechanisme wijzigt de druk waarmee het papier wordt vastgehouden op basis van de dikte van het papier
• variabel mechanisme op basis van transferkoppel stabiliseert de papieraanvoer

Dun papier
Het gebruik van een transferband in plaats van een rol verhoogt de veelzijdige inzetbaarheid van printen op dun papier.

Ansichtkaarten
Door het gebied buiten de papierbaan te blokkeren met een schot, wordt de papieradsorptie verbeterd en de verwerkingsstabiliteit van ansichtkaarten in de printer

Aanvullende technologieën voor papierverwerking

Elektrostatische neutralisator
De optionele elektrostatische neutralisator D1 neutraliseert de effecten van statische elektriciteit aanzienlijk op een breed scala aan media, waaronder enkellaags folies, synthetisch papier, waterbestendig papier en kleefpapier.
De waarde kan worden ingesteld van 0 tot 99 en kan ook worden bijgesteld tijdens productie.

Krulcorrectie
Een compacte, ingebouwde ontkruller beoordeelt en corrigeert pagina voor pagina in realtime automatisch de krulvorming van het papier, veroorzaakt door de papiersoort of beelddichtheid. Dit maakt een hoogwaardige uitvoer mogelijk met stabiel papiertransport en krulcorrectie.
De optionele interface ontkrulmodule D1 biedt extra krulcorrectiestappen, waardoor wordt bespaard op de tijd die nodig is voor aanpassingen als de printmedia vaak worden gewijzigd.

Inlegapparaat met opneemzuiger

Het optionele inlegapparaat met opneemzuiger verbetert de invoerprestaties van stofrijk papier, voorbedrukt papier met poeder, papier met een ongelijke structuur en gestreken papier.

Er wordt een stabiele en snelle invoer bereikt voor verschillende papiersoorten, van lichte tot zware en kleine vellen en baniervellen.

Stappen naar duurzamer printen

De Revoria Press EC2100 en EC2100S zijn uitgerust met een aantal energiebesparende functies, zoals de LED-printkop en Super EA-Eco-toner die het energieverbruik tijdens het printen minimaliseren.

De printers hebben ook de certificering ‘Superieure ontinktbaarheid’ ontvangen van de gerenommeerde brancheorganisatie INGEDE, wat betekent dat de toner gemakkelijk kan worden verwijderd uit het printwerk dat met deze printers is geproduceerd. Dit garandeert dat al het printwerk gemakkelijker kan worden gerecycled en verbetert de duurzaamheid van de printers verder.

De uitvoer van de Revoria Press EC2100 & EC2100S is getest conform INGEDE Methode 11 en beoordeeld volgens de ‘Beoordeling van recyclebaarheid printwerk – ontinktbaarheidscore’ (EPRC 2017).

De totaalscore was 100/100 beschikbare punten.

Ruimtebesparend ontwerp

De Revoria Press EC2100 en EC2100S zijn voorzien van een volledig nieuw ‘Vertical Development System’ en een ultracompacte LED-printkop. Dat resulteert in een 5-kleurenprinter die even groot is als zijn voorganger met 4-kleuren, de Revoria Press EC1100.

Request a product demo

Ontdek wat de de Revoria EC2100 voor uw business kan betekenen

Onderscheid uw bedrijf met printwerk van meerwaarde

Met de Revoria EC2100S kunt u printwerk met toegevoegde waarde leveren door naast CMYK gebruik te maken van bijzondere toners als vijfde kleur. Deze bijzondere toners kunnen over CMYK-kleuren worden geprint en eenvoudig worden gewisseld door de gebruiker.

De waarde van roze toner

Het kleurengamma uitbreiden

CMYK + roze verruimt het kleurengamma van rode en blauwe tinten, zodat levendigere kleuren kunnen worden geprint. Hiermee kunnen vooral levendige oranje en blauwviolette tinten worden geprint die met alleen CMYK niet mogelijk zijn. Zo kunt u ook printwerk produceren dat meer lijkt op de RGB-kleuren.

Daarnaast kunt u met de functie ‘Use Specialty Toner in RGB Simulation’ (RGB-simulatie bijzondere toner) roze, oranje en paarse kleuren helderder en levendiger printen, waardoor die nog beter gelijken op de kleuren die in RGB zichtbaar zijn op uw scherm.

Huidtinten verbeteren

Huidtinten in elke kleurtoon zijn subtieler en minder korrelig als u ook roze opneemt in de configuratie. Bovendien zorgt de unieke functie ‘Use Pink Toner to Brighten Up’ (kleuren opfleuren) in Revoria Flow ervoor dat huidtinten nog levendiger en mooier kunnen worden geprint.

De waarde van vernistoner

Met een vernistoner kunt u in perfect register een verniseffect printen op specifieke gebieden, voor opvallend, creatief en gepersonaliseerd printwerk. Dit kan ook een luxe uitstraling geven aan subtiele patronen en achtergronden, of in CMYK geprinte beelden opfleuren.

Met de vernistoner kunt u verfraaiing creëren, zoals glans of textuureffecten, of watermerken en achtergrondeffecten aanbrengen, zodat uw ontwerpen moeilijker te kopiëren zijn. De doorzichtige toner kan worden gecombineerd met CMYK-printwerk om een glanzende, gladdere afwerking en een vernisachtig effect te krijgen.

More information

Zie voor meer specifieke details onze Revoria EC2100 product brochure, deze is vanaf heden te downloaden.

De brochure downloaden

Revoria Press SC285

Nieuwste generatie 4- en 5-kleuren middenklasseprinters.

Nieuwste generatie printers

Het is tijd om uw printwerk naar een hoger plan te tillen

De Revoria Press SC285 & SC285S printers zijn uitgerust met een aantal geavanceerde technologieën die zorgen voor baanbrekende prestaties, hoge kwaliteit en veelzijdigheid in gebruik. De Revoria SC285S beschikt ook over een vijfde kleur waarmee u een breder kleurengamma en speciale effecten kunt printen om op te vallen in een steeds veeleisender markt.

Tot wel

85ppm

A4 CMYK

Tot wel

5 kleuren

52 tot 400 g

mediagewicht

Maximale mediaformaat

330 x 1300mm

mediaformaat

Waarom de Revoria Press SC285 & SC285S?

5-kleuren printwerk voor een breder kleurengamma en bijzondere effecten die opvallen

200 gepatenteerde nieuwe technologieën voor een toonaangevende veelzijdigheid in toepassingsmogelijkheden

Baanbrekende productiviteit, kwaliteit en prestaties voor een middenklasseprinter

Maak kennis met 5UPERKLEUR van Revoria. Twee nieuwe middenklasseprinters die een vijfde kleur samenbrengen met buitengewone prestaties om op te vallen in een steeds veeleisender markt.

Toonaangevende middenklasseprinters met geavanceerde kleurmogelijkheden en prestaties

De Revoria SC285 & SC285S leveren niet alleen betere prestaties, maar ook de voordelen van 5-kleurenprint, waarmee u uw bedrijf kunt onderscheiden.

Voortreffelijke benchmark printkwaliteit

Super EA-Eco-toner

Daarnaast worden verlopen, halftonen en middentonen gedetailleerder en puntvormen natuurgetrouwer gereproduceerd, wat een uitzonderlijk hoge printkwaliteit geeft.

LED-printkop

De Revoria Press SC285 & SC285S maken gebruik van een LED-printkop met hoge resolutie, waarmee ze printwerk van uitzonderlijk hoge definitie produceren:

2400 x 2400 dpi LED-printkop
Levert uitvoer in hoge resolutie voor scherpe lijnen en beelden, wat printen in hoge definitie mogelijk maakt.

Realtime, intelligente printoptimalisatie

De Revoria Press SC285 en SC285S zijn voorzien van optionele slimme monitorfunctie D1 die de kleur en registernauwkeurigheid van de voor- en achterzijde van printopdrachten monitort tijdens het printen.

Maximale productiviteit en inzetbaarheid

Printen op topsnelheid van 85 ppm met alle papiergewichten

De Revoria Press SC285 en SC285S kunnen maximaal 85 ppm printen in A4-formaat met CMYK, en maximaal 47 ppm in A3-formaat met CMYK. Deze snelheid wordt bereikt voor alle mediagewichten tussen de 52 en 400 g.

Nieuwe bias transferband

Het gebruik van een nieuw Bias Transfer Band-systeem (BTB) in plaats van de conventionele Bias Transfer Rol (BTR) maakt het papiertransport stabieler en dus betrouwbaarder, zodat u nog meer toepassingen kunt printen. Het nieuwe systeem past de nipdruk automatisch aan op basis van de dikte van het papier, wat de overdracht van de toner verbetert. Dit mechanisme is nieuw voor de Revoria SC285 & SC285S en produceert een superieure printkwaliteit, met name op reliëfpapier.

Transfermechanisme aan voorrand

Fujifilm heeft de SC285 & SC285S uitgerust met een vliegwiel dat de transferbandrol een traagheidskracht geeft voor een stabiele aandrijving. De rotatie van het vliegwiel en de traagheidskracht onderdrukken de trillingen van de transferband, waardoor een stabiele overdracht van media wordt verkregen, zelfs bij zwaar papier.

Nieuwe ontwikkeltechnologie

In het nieuwe verticale ontwikkelsysteem dat in de SC285 & SC285S wordt gebruikt, wordt het ontwikkelingsmateriaal vernieuwd voordat het wordt teruggevoerd naar de ontwikkelrol. Op deze manier is al het gebruikte ontwikkelingsmateriaal altijd ververst en in optimale conditie, waardoor de Revoria SC285 & SC285S ook na verloop van tijd mooi blijven printen, vooral op dik, ruw en reliëfpapier.

Toonaangevende mogelijkheden voor papierverwerking

De Revoria Press SC285 en SC285S hebben nu een reeks geavanceerde markeertechnologieën met verbeterde papierverwerkingsmogelijkheden, waardoor meer soorten toepassingen kunnen worden geprint en de inzetbaarheid van de machine toeneemt voor een breed scala aan substraten.

Dik papier, enveloppen
Twee nieuwe technologieën voor papiertransfer leveren een toonaangevend papierverwerkingsvermogen voor dik papier en enveloppen:

Dun papier
Het gebruik van een transferband in plaats van een rol verhoogt de veelzijdige inzetbaarheid van printen op dun papier.

Ansichtkaarten
Door het gebied buiten de papierbaan te blokkeren met een schot, wordt de papieradsorptie verbeterd en de verwerkingsstabiliteit van ansichtkaarten in de printer

Aanvullende technologieën voor papierverwerking

Inlegapparaat met opneemzuiger

Het optionele inlegapparaat met opneemzuiger verbetert de invoerprestaties van stofrijk papier, voorbedrukt papier met poeder, papier met een ongelijke structuur en gestreken papier.

Er wordt een stabiele en snelle invoer bereikt voor verschillende papiersoorten, van lichte tot zware en kleine vellen en baniervellen.

Stappen naar duurzamer printen

De Revoria Press SC285 en SC285S zijn uitgerust met een aantal energiebesparende functies, zoals de LED-printkop en Super EA-Eco-toner die het energieverbruik tijdens het printen minimaliseren.

De uitvoer van de Revoria Press SC285 & SC285S is getest conform INGEDE Methode 11 en beoordeeld volgens de ‘Beoordeling van recyclebaarheid printwerk – ontinktbaarheidscore’ (EPRC 2017).

De totaalscore was 100/100 beschikbare punten.

Ruimtebesparend ontwerp

De Revoria Press SC285 en SC285S zijn voorzien van een volledig nieuw ‘Vertical Development System’ en een ultracompacte LED-printkop. Dat resulteert in een 5-kleurenprinter die bijna even groot is als zijn voorganger met 4-kleuren, de Revoria Press SC180/170.

Kleuren afstemmen op eerder werk

Revoria Flow bevat een nieuwe functie genaamd User Image Colour Matching (UICM) die wordt gebruikt om kleuren af te stemmen op die uit eerder werk, zelfs als die op een andere pers zijn geprint/gedrukt. Dit werkt zelfs als u de instellingen of uitvoercondities van die opdracht niet kent en stelt u in staat om opdrachten opnieuw te printen in exact dezelfde kleur.

Dit is mogelijk omdat de Revoria Press SC285 & SC285S een scanunit bevatten waarmee een eerdere opdracht kan worden gescand. Revoria Flow maakt vervolgens een apparaatkoppelingsprofiel voor de CMYK-kleuren en wijst dit toe aan de opdracht.

Request a product demo

Ontdek wat de de Revoria SC285 voor uw business kan betekenen

Onderscheid uw bedrijf met printwerk van meerwaarde

Met de Revoria SC285S kunt u printwerk met toegevoegde waarde leveren door naast CMYK gebruik te maken van bijzondere toners als vijfde kleur. Deze bijzondere toners kunnen over CMYK-kleuren worden geprint en eenvoudig worden gewisseld door de gebruiker.

De waarde van roze toner

Het kleurengamma uitbreiden

Huidtinten verbeteren

De waarde van vernistoner

More information

Zie voor meer specifieke details onze Revoria SC285 product brochure, deze is vanaf heden te downloaden.

De brochure downloaden

Revoria Press SC170/80

Compact and highly
productive printer

High quality, productive and versatile

Compact mid-range printer suitable for a wide range of applications

The Revoria Press SC180 / SC170 is a compact and highly productive printer capable of high resolution printing. With its versatile media handling, including long and heavyweight paper, and a wide range of finishing, it is a perfect, compact printer for a wide range of applications.

Fantastische

2400 dpi, 10-bit

print resolution

Versatile

52 to 400g

mediagewicht

Tot wel

80ppm

A4 print speed

Why Revoria Press SC170/80?

High Quality

2400 dpi and EA-Eco toner for superb results on coated or uncoated paper

Productive

80ppm on both coated and uncoated paper up to 220g in weight

Versatile

Handles media weights from 52 to 400g and long banner paper up to 1200mm

Automatic document feeder

VCSEL-ROS / EA-Eco toner

Air suction mechanism / multi-feed detection device

Compact belt roll fuser

Real time curl correction

Built-in twin decurler

Uw volledige ondersteuningspakket

Our expert team takes time to understand your unique business requirements and goals for print-on-demand service and support

Download voor meer informatie

Oplossingen voor bedrijfsdrukwerk

One partner for the best in inkjet and toner. Find out more about our full range of digital presses.

Ontdek het commerciële assortiment

Request a product demo

Find out what the Revoria SC170/80 can do for your business

Belangrijkste kenmerken

Discover more about the advanced technologies and capabilities built into the Revoria Press SC170/80

Highly productive and easy to use

High productivity of 80 ppm on mixed media jobs

The Revoria Press SC180 & SC170 achieves high productivity printing of 80ppm on both coated and uncoated paper up to 220g in weight. Even on heavier weight media between 300g and 400g, a high speed is maintained at 60ppm.

Printing Speed (uncoated)

Printing Speed (coated)

Optional Air Suction Feeder ensures ultra-reliable media handling for all media types
Like an offset feeder, each sheet is picked up and delivered securely by the shuttle head using air suction, improving the paper feeding performance for low quality, textured and coated media. This system is different to most others on the market, giving ultra-reliable and consistent paper feeding and therefore print performance.

Simple Image Quality Adjustment (SIQA) system saves operator time
SIQA is an adjustment mechanism to optimise image-to-media alignment, density uniformity and image transfer parameters. This saves operator time and improves productivity by eliminating the need to manually print and measure every job.

Versatile

Handles various media weights from 52g to 400g

Everything from thin folded flyers to thick business cards can be printed. Additionally, not only can it handle heavier weight longer papers (350g up to 660mm, 300g up to 864mm) but the efficient media handling and versatility mean a wide range of customer needs can be met. In addition, high speed envelope printing can be achieved without an additional fuser.

Wide range of paper sizes, along with long banner paper of 1200 mm

The printer supports a wide range of paper sizes, from 148 x 98 mm (smaller than a postcard) up to 1200 x 330mm banner paper. The Multi Sheet Inserter for banner printing can print single-sided long paper from 660 x 330mm up to 1200 x 330mm, depending on the configuration, and duplex long paper up to 864 x330 mm, opening up new application and business opportunities. The Revoria Press SC180 & SC170 perform alignment adjustments to prevent paper skew or mis-registration which can often occur for longer banner papers to
ensure ultra-reliable operation.

High Quality

10-bit processing and half tone smoothing

10-bit processing results in up to 1024 halftones (instead of 256 with an 8-bit system) meaning extra control and higher quality reproduction can be achieved. In addition, graduation correction is used on images and vector graphics, faithfully reproducing fine tints, gradations of colour and subtle blends between colours. This is especially valuable when printing colour gradients, skin tones and shadows.

2400 dpi resolution and excellent registration

The VCSEL-ROS laser provides 2400 dpi print resolution while the energy efficient EA-Eco toner* achieves superb results on either coated or uncoated paper to deliver high quality images comparable to offset printing. In addition, the front/back registration of up to 0.5mm (0.8mm from standard trays) ensures high quality duplex printing.

Finishing applications

Discover the range of creative possibilities provided by the modular feeding and finishing options available as part of the Revoria Press SC170/80

ontdek meer

Find more details and key specifications in the Revoria SC170/80 product brochure, available for download now.

De brochure downloaden

Revoria Press EC1100

Highly productive and versatile production printer

High quality, productive and versatile

Superb mid-range press suitable for a multitude of applications

The Revoria Press EC1100 is a versatile production printer capable of high resolution printing at faster production speeds. It is able to support a wide range of applications thanks to its creative finishing capabilities and versatile media handling, including long and heavyweight paper up to 400g.

Fantastische

2400 dpi, 10-bit

printresolutie

Tot wel

400g

paper weight

Tot wel

100 ppm

A4 print speed

Why Revoria Press EC1100?

High quality

2400 dpi and EA-Eco toner for superb results on coated or uncoated paper

Productive

100ppm on both coated and uncoated paper up to 300g in weight

Versatile

Handles media weights from 52g to 400g and long banner paper up to 1200mm

Control panel

VCSEL-ROS / EA-Eco toner

Air suction mechanism / multi-feed detection device

Gate-type registration mechanism

Compact belt roll fuser

Built-in twin decurler

Compact paper cooling device

Inline sensor

Real time curl correction

Oplossingen voor bedrijfsdrukwerk

One partner for the best in inkjet and toner. Find out about our full range of digital presses.

Ontdek het commerciële assortiment

Request a product demo

Find out what the Revoria EC1100 can do for your business

Belangrijkste kenmerken

Discover more about the advanced technologies and capabilities built into the Revoria Press EC1100.

Highly productive and easy to use

The Revoria Press EC1100 achieves high productivity printing of 100ppm on both coated and uncoated paper up to 300g in weight. Even on heavier weight media between 300g and 400g, a high speed is maintained at 80ppm.

Optional Air Suction Feeder ensures ultra-reliable media handling for all media types

Like an offset feeder, each sheet is picked up and delivered securely by the shuttle head using air suction, improving the paper feeding performance for low quality, textured and coated media.

This system is different to most others on the market, giving ultra-reliable and consistent paper feeding and therefore print performance.

Automation with inline sensor

The Revoria Press EC1100 has an inline sensor which automatically makes adjustments for a number of critical production parameters, including the image-to-media alignment, image transfer, density uniformity and tone reproduction curve.

This saves time, optimises quality and improves the efficiency of production for simple, more reliable operation. This is particularly useful for longer banner paper, which has a tendency to skew or suffer from mis-registration without these automated adjustments.

Optimise print conditions for each paper type with built in media library

Minimise adjustments when setting up print jobs by using pre-registered paper type settings in the media library such as voltage and curl. Alternatively, you can customise the pre-loaded recommended paper list and save up to 1,000 different paper type setting for faster setup.

Auto sheet clearing after paper jam

Significantly reduce the time taken to clear a paper jam with the automated clearing of the remaining paper after a jam. When a paper jam does occur, offset pages are inserted to identify any missing or repeated pages.

Versatile

Handles various media weights from 52g to 400g

Wide range of paper sizes, along with long banner paper of 1200 mm

The printer supports a wide range of paper sizes, from 148 x 98 mm (smaller than a postcard) up to 1200 x 330mm banner paper. The Multi Sheet Inserter for banner printing can print single-sided long paper from 660 x 330mm up to 1200 x 330mm, depending on the configuration, and duplex long paper up to 864 x330 mm, opening up new application and business opportunities. The Revoria Press EC1100 performs automated alignment adjustments to prevent paper skew or mis-registration which can often occur for longer banner papers to ensure ultra-reliable operation.

High quality

10-bit processing and half tone smoothing

2400 dpi resolution and excellent registration

The VCSEL-ROS laser provides 2400 dpi print resolution while the energy-efficient EA-Eco toner* achieves superb results on either coated or uncoated paper to deliver high quality images comparable to offset printing. In addition, the front/back registration of up to 0.5mm (0.8mm from standard trays) ensures high quality duplex printing.

* Emulsion Aggregation-Eco Toner

Finishing applications

Discover the range of creative possibilities provided by the modular feeding and finishing options available as part of the Revoria Press EC1100

More information

Find more details and key specifications in the Revoria EC1100 product brochure, available for download now.

De brochure downloaden

Acuity Prime Hybrid

Dedicated hybrid for
rigid and roll print

Versatile & ultra reliable

A game changing, LED UV hybrid machine capable of rigid and roll printing

The design of the printer is based on the award-winning Acuity Prime, including the printhead carriage, ink system, Automatic Printhead Maintenance System (APMS) and software interface.

Tot wel

141 m²/hr

roll-to-roll

Up to 7 channels

CMYK+W+Cl

plus primer

Tot wel

51mm

media thickness

Why Acuity Prime Hybrid?

Versatile

Handles flexible and rigid media up 51 mm thick, and roll media up to 2m wide

Reliable

Benefits from an ultra-reliable and long lasting air cooled LED UV curing system

Operator-friendly

Sliding draw design allows for easy access to ink pumps and filters

Native 7 picolitre, 3 level greyscale printheads

4 vacuum zones

2 m width

Intuitive GUI

Long lasting, air cooled LED UV curing system

Uvijet HM high performance inks

7 channels (CMYK plus optional White, Clear and Primer)

Prints on heat-sensitive materials

Request a demo

Ontdek de voordelen persoonlijk met een productdemonstratie.

Een afdrukvoorbeeld aanvragen

Bekijk de kwaliteit die je kunt bereiken met de Acuity Prime-reeks

Belangrijkste kenmerken

The Acuity Prime Hybrid is a true Hybrid machine, which means there is no
trade-off and none of the compromise that you would find in an older machine when switching between both rigid and roll media.

Up to 7 channels

The Acuity Prime Hybrid can be configured with up to 7 channels, with CMYK as standard, and optional White, Clear and Primer, and produces stunning quality print, able to produce droplet sizes down to 7pL. It handles flexible and rigid media up 51 mm thick, and roll media up to 2m wide, and benefits from an ultra-reliable and long lasting air cooled LED UV curing system.

It features a 4 zone vacuum system, and can produce print at speeds up to 141m2/hr. The printer is suitable for an incredibly wide range of applications, but can also be configured with an optional primer, extending the range of applications that can be printed even further.

Safety features

The Acuity Prime Hybrid also has a range of built-in safety features designed to maximise print uptime, which include anti-collision protection, with crash sensors deployed at both ends of the carriage, and an ioniser bar that reduces static on the media surface. Like the Acuity Prime, the printer also benefits from remote operation.

Designed with the operator in mind

Cost saving isn’t just about reducing the price of goods or outgoings, it’s also making sure the machine is running when and how you need it to. A huge part of this is making sure the printer is easy to use but also easy to maintain.

The Acuity Prime range prides itself on being extremely intuitive, from its user-friendly GUI, to accessible printheads for ease of maintenance and the Acuity Prime Hybrid is no exception. By including the unique Automatic Printhead Maintenance System, gone are the days of needing a time-consuming maintenance check on a Monday morning after a longer weekend, the APMS system ensures that the Acuity Prime Hybrid is ready to print whenever you are

Print modes and speeds

Prime Performance

Suitable for use with a wide range of media

Dedicated Hybrid

With the heavy-duty media handling system which allows rolls up to 100kg to be printed, a range of tricky to run media such as wallpaper, contravision and self-adhesive vinyl which are often prone to wrinkling, handle exceptionally on the Acuity Prime Hybrid.

Prime applications

Thanks to the Uvijet HM, HF and HZ ink ranges from the award-winning manufacturing plant in Broadstairs, UK, the Acuity Prime Hybrid is able to adhere to a wide range of roll media including contravision & window film, which are extremely heat sensitive LED curing materials, as well as textiles, often used for graphics and black back polyester.

This successful ink technology paired with the industrial build quality of the Acuity Prime Hybrid ensure that bold, creative applications are possible.

Quick changeover between rigid and roll media

Unlike some competitor machines, the Acuity Prime Hybrid is able to switch from rigid to roll-to-roll media seamlessly and within under a 10 minute changeover period, ensuring minimal downtime and optimal performance.

Fantastic ROI

Much like the entire Prime range, the Acuity Prime Hybrid offers its customers excellent return on investment, thanks to the full colour gamut provided by Fujifilm’s patented ink technology, maximum throughput achieved with the ability to print multiple boards with the 2m bed size, plus sellable quality prints even in draft mode.

ontdek meer

Lees meer over Acuity Prime Hybrid in onze nieuwe gids

Download de assortimentsgids

Wide format printing solutions

Find out more about the uncompromising quality and versatility of our ever-growing Acuity range

Ontdek het verschil

Revoria XMF PressReady

Revolutionary digital print production workflow

Advanced digital workflow

Streamline digital production with automated workflows

XMF PressReady is a revolutionary digital print production workflow system to receive, pre-flight, impose, gang, sort and deliver “Press Ready” jobs to digital presses using automated production flows. It allows print service providers to automate ordinary and repetitive tasks, allowing press operators to focus on more important aspects of the production process.

Supports

all digital

presses

Automate

digital

production

Elimineer

routine

tasks

Waarom XMF PressReady?

One workflow

Full integration with Fiery and Fujifilm Revoria Flow DFEs to manage all digital
presses with one system

Economical

Eliminate routine tasks, improve production efficiency and lower running costs for a better ROI

Gebruiksvriendelijk

Highly intuitive and simple interface allows system to be scaled across teams of
any size

Request a demo

Explore the benefits that XMF PressReady could bring to your business

Belangrijkste kenmerken

XMF PressReady is unique in integrating not only with Revoria digital presses, but any connected digital press using a Fiery DFE

Hybrid digital & offset print production

XMF PressReady is integrated with Fujifilm’s established and respected XMF Workflow system, allowing print businesses to manage both offset and digital production via one integrated workflow, making it an ideal solution for those who offer hybrid printing services. When used in combination with Fujifilm’s Revoria Press PC1120 and Revoria Flow DFE, XMF PressReady, can completely automate the flow of print work from order intake to printed product by preconfiguring and automating the flow of work through the Revoria Flow DFE.

Integration

XMF PressReady can integrate with other systems such as Management Information Systems (MIS) and web to print systems allowing up stream systems to be fully connected to the digital print production flow.

Print management across all vendor presses

XMF PressReady is unique in integrating not only with Revoria digital presses, but any connected digital press using a Fiery DFE. This allows print service providers to manage digital presses from
multiple vendors using one system, giving visibility of the print job status, the print job queue, media information, ink levels and much more.

Conditional automation

Able to integrate seamlessly into a range of established workflow environments, XMF PressReady offers multiple workflows that can be configured to make production decisions based on size, quantity, media, and page count. XMF PressReady eliminates the need for manual intervention, saving valuable time and reducing the possibility of operator error.

Streamline production

Fujifilm’s XMF PressReady brings a new level of efficiency to digital print production, providing print service providers with a powerful, flexible, and efficient workflow system that can automate processes, streamline production, and save valuable time by minimising errors.

XMF PressReady workflow

ontdek meer

Learn more about XMF PressReady and our other print solutions in our new commercial range guide

Nu downloaden

Jet Press FP790

Digital inkjet press for flexible packaging

Three presses in one

Print mainstream flexo jobs digitally, at rotogravure quality

The Jet Press FP790 has been designed to help printers and converters adapt to changing market dynamics that are driving shorter print runs and product life cycles, faster delivery times and more sustainable production, whilst also adhering to the regulatory requirements of flexible packaging.

Superb

1200 x 1200dpi

Print resolution

Tot wel

50m/min

Print speed

Tot wel

790mm

Substrate width

Why Jet Press FP790?

Hoge productiviteit

Print speed of 50 m/min (164 feet per minute), no matter the number of colours.

Wide colour gamut

Achieve special brand and spot colour matching with no special inks.

Sustainable print process

Able to minimise waste and reduce the number of consumables.

Inline corona

Vibrant colour

Automatic register

Digital print unit (ww) and drying

Unwinder

High resolution

Digital print unit (cmyk) and drying

Image inspection

Rewinder

Vraag je monster aan

Vul het formulier in om uw monster van flexibele verpakking aan te vragen

Suitable for mainstream flexible packaging

The Jet Press FP790 digital press has been designed to be suitable for mainstream flexible packaging applications, thanks to a number of key features. Firstly, the Jet Press FP790 digital press produces ultra-high print quality, wide gamut print similar to the Jet Press 750S, making it possible to convert analogue flexo and rotogravure jobs to digital.

Hoge productiviteit

The maximum substrate width is 790mm (31 inches) with a productivity of 50 m/min (164 feet per minute), no matter the number of colours. The high machine uptime and ability to change printing jobs and design adjustments within a matter of minutes contribute to the overall improvement of production efficiency of the entire factory.

Critically, the Jet Press FP790 is also able to fit into existing production processes with no other capital investments, along with being a much more sustainable solution than its analogue counterparts.

Fits existing production processes

With the challenging demands of the flexible packaging market, particularly the short turnaround times and regulatory requirements, Fujifilm has carried out extensive testing of printed output from the Jet Press FP790 with various laminating, slitting and finishing processes, to ensure customers of the press are in the best possible position to maximise the production opportunities from day one.

Fujifilm extensively tested Henkel’s renowned portfolio of laminating adhesives to ensure compatibility with the Jet Press FP790 ink as well as verify adhesion properties and lamination performance in post-press production, to guarantee the highest quality output. Given the excellent results and positive outcomes from these rigorous tests, Henkel’s solvent-free laminating adhesives are Fujifilm’s recommended solution for use with the Jet Press FP790.

Fujifilm also successfully tested Nordmeccanica’s Simplex range of two-layer laminating machines for solvent-less adhesives. The environmental benefits of the Jet Press FP790, combined with Henkel’s solvent-free adhesives and Nordmeccanica’s solvent-less lamination technology, delivers a truly sustainable production solution. In addition, it will enable packaging converters to remain compliant with the increasingly stringent environmental regulations that are now commonplace throughout the industry.

By collaborating with renowned and leading manufacturers of pre-press and post-press
technologies, Fujifilm can clearly demonstrate that its new Jet Press FP790 is fully compatible and integrates effortlessly into existing production environments offering a ‘plug and play’ digital solution that delivers the highest quality finished packaging with minimal testing, training or setup.

XMF Packaging – powered by HYBRID Software

Fujifilm’s Jet Press FP790 will feature a unique, smart Digital Front End (DFE) and unified workflow solution developed specifically by HYBRID Software to optimise the productivity and output of Fujifilm’s press.

This new XMF Packaging DFE is the first of its kind to be developed by a software company for use in the packaging market, and is a result of a close working partnership between Fujifilm’s R&D team and HYBRID’s specialist software developers.

Based on proven technology, the web-based,open architecture production workflow offers fully automated pre-press functionality to ensure the Jet Press FP790 press offers accelerated turnaround times, maximum productivity and reduced operating costs. In addition, its modular configuration allows for greater workflow expansion and upstream customisation to cater for specific user requirements.

A more sustainable print process

Fujifilm employs environmentally friendly water-based primers and inkjet technologies, which meet or exceed all regulatory requirements for flexible packaging printing. The Jet Press FP790 is also able to minimise waste, reduce the number of consumables associated with traditional analogue production, and totally eliminate all elements of the plate-making process.

Wide colour gamut and ultra-high quality

Using 1200 X 1200 dpi resolutions with CMYK inks, the Jet Press FP790 can achieve more than 90% of the Pantone® colour gamut, while also using two white ink channels for delivering high white opacity, all achieved with unprecedented colour stability. The wide colour gamut allows converters to achieve special brand and spot colour matching with no need for additional special inks.

Comparison of the color gamut of Jet Press FP790

Displayed L*a*b* space in a*b* plane

Want to know more?

Find out more about the Jet Press FP790 in our new Label & Packaging Range guide, available for download here.

Download de assortimentsgids

Analogue. Digital. Sustainable.

Fujifilm for packaging: A story in three parts.

Read the Article

Acuity Ultra Hybrid LED

Designed for rigid and flexible media, offering superb, high quality printing in a 3.3m platform.

One platform. Unlimited results.

The Acuity Ultra Hybrid LED delivers an unrivalled range of applications at both high quality and high speed.

The Acuity Ultra Hybrid LED is a high-end printer designed for rigid and flexible media, offering superb, high quality printing in a 3.3m platform

Tot wel

218 m²/hr

roll-to-roll

Native

3.5 picolitre

greyscale printheads

Tot wel

1200 x 1200 dpi

print resolution

Neem contact met ons op

Why Acuity Ultra Hybrid LED?

Near photographic quality printing of a huge range of applications at high speeds

Scalable architecture that can grow and change as business demands evolve

Intelligent design and new high performance ink for maximum versatility

Media load and unload tables

Intelligent vacuum control system

Damage-resistant belt

Intuitive GUI

Een monster aanvragen

To request a print sample, click below

Request a demo

Discover the benefits for yourself

Ultra-high quality

The Acuity Ultra Hybrid LED uses the same head carriage as the Acuity Ultra R2, capable of ejecting greyscale drops down to 3.5pL in size to deliver superb print quality. Combined with an industrial build quality, a linear motor head carriage drive and Fujifilm’s high performance Uvijet UH inks, the very best print quality is guaranteed.

Heavy duty chassis

Like the Acuity Ultra R2, the Acuity Ultra Hybrid LED is built on a substantial welded steel construction, together with solid steel bars, which contribute to the machine’s 8.3T weight. This design not only delivers a robust construction, it also ensures that the printer displays very little vibration during operation, further enhancing print quality.

Linear motor head carriage drive

Many hybrid printers use a belt drive to move the print carriage, often resulting in a reduced life span as well as impacting print quality. The Acuity Ultra Hybrid LED uses a linear motor drive for the head carriage delivering travel speeds of 1900mm per second when using the fast carriage travel speed. The carriage movement is quiet and free from vibration, travelling along dual rails with the carriage supported by 6 large race bearings.

Designed with the operator in mind

A range of advanced features have also been incorporated into the design of the Acuity Ultra Hybrid LED to improve operation and maximise uptime. These include:

Media tension buttons controlling the roll functions of the machine are located on both the input and output sides for ease of use
The input media roller is adjustable, moving up and down, for improved tension, and to help keep the roll media flat and wrinkle free
The durable aluminium media shafts cater for either single 3.3m rolls, or two rolls each up to 1.6m wide. The printer uses a special airshaft which allows two rolls of the same media having different diameters to be run at the same time

Uvijet UH ink

Fujifilm has developed a new high performance LED curing ink for use in the Acuity Ultra Hybrid LED, specifically designed to give the adhesion performance needed in a hybrid solution. However, the ink still delivers the same high coverage and print quality as Fujifilm’s other Uvijet AU and GS inks, with customers also able to benefit from the same low ink usage.

The Uvijet UH ink set consists of six standard colours (CMYKLcLm) and an optional white ink. The printer can be configured with two white ink channels to maximise throughput speeds and print density.

The Acuity Ultra Hybrid LED with white ink allows flood white under-printing for non-white media, over-printing white for backlit applications on transparent media and/or printing white as a spot colour. The new ink range has both Greenguard Gold and AgBB certification.

Applications

Ultra-versatile

The combination of intelligent design features and Fujifilm’s new Uvijet UH high performance ink, ensures that the Acuity Ultra Hybrid LED is one of the most versatile platforms on the market, able to produce an unrivalled range of applications at both high quality and high speed.

Print on rigid media with ease

The Acuity Ultra Hybrid LED’s belt transport and intelligent vacuum systems are truly unique, meaning it can print on a range of rigid substrates previously only possible on dedicated flatbed systems.

This means low cost Correx products for short term signage applications such as for sale signs and building hoardings, can be printed at high speed with multiple panels (up to 5 across the bed) continually printed with a single operator.

Double up with multi-layer capability

In addition, the Acuity Ultra Hybrid LED can print onto Dibond and Acrylics, utilising multilayer printing and white for reverse printing, and two sided applications.

These applications take advantage of the superb transport system and accurate dot placement, and can deliver high margins and additional revenues, previously only possible with a dedicated printer.

Two rolls at once

The Acuity Ultra Hybrid LED can also print 2 x 1.6m rolls, even with different diameters, as the shafts have a differential in the middle meaning the rolls can spin at different speeds.

All rolls are transported perfectly through the printer, producing high quality results on materials such as self-adhesive vinyl, pop up materials for roller banners, floor graphics and billboard paper all delivered at high speed.

Highlights are a clear winner

For both rigid and roll, the Acuity Ultra Hybrid LED can also print white on a wide range of clear materials such as clear self-adhesive PVC, optically clear polyester and polypropylene – all high margin applications for retail applications.

It also capable of printing on wall covering materials, either short rolls up to 1.6m with a textured finish, or on 3.2m seamless wallcoverings for business applications such as hotels and retail spaces.

Short runs to maximise productivity

Roll feeders located on the tables mean many short run applications can be printed economically, with very little waste material and fast change-around times, making the Acuity Ultra Hybrid LED a truly versatile production system.

The new blueprint for wide format

Find out more about why the new Acuity range represents the new blueprint for wide format

Lees het artikel

ontdek meer

Lees meer over Acuity Ultra Hybrid LED in onze nieuwe gids

De brochure downloaden

ApeosPro C Series

C810, C750 & C650 – Light production printers offering exceptional quality

High quality light production printers

At home in a corporate office, light production professional print environment, or design agency

The ApeosPro C Series is an entry level range of four-colour printers that offer exceptional quality for businesses with lower production volumes. They are built on a next-generation platform, with all printers in the range able to produce superb, high quality print on a wide range of substrates and for a wide range of applications.

Superb

2400 x 2400 dpi

print quality

Print speed

Up to 81 ppm

Full colour

Paper weight

52 to 350 gsm

Bypass tray

Why ApeosPro C Series?

World’s first LED printhead with 2400 x 2400 dpi resolution

Versatile enough to print a wide range of applications

High productivity levels with continuous operation

Interface Decurler

Inserter D1

High Capacity Stacker A1

Crease / Two-sided Trimmer D2

Folder Unit CD2

Finisher D6 / Finisher D6 with Booklet Maker

Square Back Trimmer D1

Ultra-high quality output

The ApeosPro C Series benefits from the world’s first high resolution LED printhead, which produces incredible, high definition print. It is also possible to maintain high print quality levels with very simple adjustments.

The world’s first* high resolution LED printhead

2400 x 2400 dpi resolution
LED printhead produces a very thin LED beam to write the image
The exposure unit does not vibrate because there is no drive mechanism, meaning image reproduction is incredibly stable
The LED printhead consumes less energy, resulting in lower power consumption

* Utilising dry-electrophotographic toner, as of March 2021 and according to Fujifilm research.

Suitable for a wide variety of paper sizes and thicknesses

The ApeosPro C Series printers are able to print on a wide range of paper sizes and thicknesses, making them suitable for the production of many different types of print.

Suitable for paper sizes from postcards to long sheets of paper, up to a maximum size of
330 x 1300 mm
Supports a wide range of thicknesses from 52 gsm lightweight paper to 350 gsm cardstock paper
Prints beautifully, even on envelopes and embossed paper with an uneven surface

Advanced security features

Information is an important asset which should be protected at all cost. The ApeosPro C Series printers incorporate a range of security features to safeguard important information.

User authentication and permissions
Protection against unauthorised access to higher level management functions
Protection against software misuse
Encryption of documents stored on the printer, and communication data between printer
and PC
Prevention of issues caused by operator errors

High productivity levels with continuous operation

The ApeosPro C Series printers offer excellent durability and high productivity levels with continuous operation possible.

Achieve print speeds as high as 81 x A4 ppm with the C810, 75 ppm with the C750, and
65 ppm with the C650
High capacity paper feeder holds up to 7360 sheets*
It is possible to replace toner cartridges and add paper without stopping the print job in progress, therefore maximising printer uptime and productivity
Low wear photoconductor drum with long life reduces the frequency of drum replacements

Stable paper feed, whatever the substrate type

The ApeosPro C Series printers are incredibly versatile, thanks to a number of key features:

A built-in sensor detects any misalignment of paper traveling at high speeds andautomatically corrects it
By adjusting the force applied to the paper according to the paper thickness, a stable paper feed and high registration accuracy are achieved, even with thicker cardstock
A built-in decurler flattens any possible paper curl, which helps guarantee the stable feed of paper. In addition, as an option, the printers can monitor any paper curl that is present, and make adjustments in real time to further minimise any potential paper feed inconsistencies.
The optimum output conditions for each paper type, such as the
transfer conditions, can be registered and stored (maximum: 100)
so that high quality output can be achieved efficiently simply by selecting the correct paper type.

See for yourself..

See what the ApeosPro C Series can do for your business

Bekijk de video

Een monster aanvragen

Bekijk de kwaliteit die je kunt bereiken met de ApeosPro C-serie

Finishing applications

Versatile post-processing with a range of in-line finishing options

From printing to post-processing, the ApeosPro printers are incredibly versatile, making it possible to produce many different types of finished print.

Square Back

High quality booklets with a square back finish for a flat book spine.

Crease

Crease function to create unique accordion folds for promotional materials. Up to five creases can be made for mountain and valley folds.

ontdek meer

Learn more about the ApeosPro C Series by downloading the product brochure

De brochure downloaden

Case study – Emmerson Press

Emmerson Press becomes the first UK print business to invest in Fujifilm’s innovative ApeosPro C810 toner press.

Jet Press 1160CFG

Jet Press – setting new standards

Groundbreaking digital inkjet web press

Tot wel

160 metre

per minute

4 colour

CMYK

printing

High coverage

1200 x 1200 dpi

quality

Wide

64 to 250 g

paper weights

Why Jet Press 1160CFG?

Groundbreaking new digital inkjet press for commercial web applications

Folding carton packaging

A press that combines high quality and high speed

Meer informatie…

Heeft u vragen? Neem hieronder contact met ons op:

Revoria Press EC2100

Nieuwste generatie printers

Het is tijd om uw printwerk naar een hoger plan te tillen

Tot wel

100ppm

A4 CMYK

Tot wel

5 kleuren

52 tot 400 g

mediagewicht

Maximale mediaformaat

330 x 1300mm

mediaformaat

Waarom de Revoria Press EC2100 & EC2100S?

Toonaangevende middenklasseprinters met geavanceerde kleurmogelijkheden en prestaties

Request a product demo

Request a demo – Revoria Press EC2100

Onderscheid uw bedrijf met printwerk van meerwaarde

De waarde van roze toner

De waarde van vernistoner

More information

Heeft u vragen? Neem hieronder contact met ons op:

Revoria Press SC285

Nieuwste generatie printers

Het is tijd om uw printwerk naar een hoger plan te tillen

Tot wel

85ppm

A4 CMYK

Tot wel

5 kleuren

52 tot 400 g

mediagewicht

Maximale mediaformaat

330 x 1300mm

mediaformaat

Waarom de Revoria Press SC285 & SC285S?

Toonaangevende middenklasseprinters met geavanceerde kleurmogelijkheden en prestaties

Request a product demo

Request a demo – Revoria Press SC285

Onderscheid uw bedrijf met printwerk van meerwaarde

De waarde van roze toner

De waarde van vernistoner

More information

Heeft u vragen? Neem hieronder contact met ons op:

Revoria Press SC170/80

High quality, productive and versatile

Compact mid-range printer suitable for a wide range of applications

Fantastische

2400 dpi, 10-bit

print resolution

Versatile

52 to 400g

mediagewicht

Tot wel

80ppm

A4 print speed

Why Revoria Press SC170/80?

Uw volledige ondersteuningspakket

Oplossingen voor bedrijfsdrukwerk
